REVOLUTIONAIR™ NEEDLE THREADING

Engage the RevolutionAir™ threader, push a button and the Acclaim’s needles are threaded! Baby Lock’s RevolutionAir Threading makes setting up your machine faster and easier than ever, every single time.

REVOLUTIONAIR™ LOOPER THREADING

Insert thread into one of the Acclaim’s threading ports, push the button and a gust of air quickly pushes it through the patented tubular loopers, exactly where you need it every time. Tangles, knots and breakage are now a thing of the past!

AUTOMATIC THREAD DELIVERY SYSTEM

Set the Acclaim to the type of stitch you want and get started! The Acclaim delivers a balanced stitch on any fabric with any type of thread.

PURE LIGHTING WITH 3 LED LIGHTS

Clearly see every stitch, fabric and thread color under three bright LED lights.

WIDER WORKSPACE – 2" TO THE RIGHT OF THE NEEDLE

Easily serge larger projects with room to spare. You'll love adding decorative stitching to yards and yards of fabric.

FULL-FEATURED SINGLE UNIT DIFFERENTIAL FEED

We’ve taken the differential feed to a new level by adding a single-unit feed dog mechanism. This ensures stronger feeding as well as consistent gathering on all fabrics.

4/3/2 THREAD SERGING

Finish projects with quality and versatility - easily switch from 4, 3 or 2 thread rolled hemming options.

ADVANCED KNIFE DRIVING AND ONE-WAY CLUTCH SYSTEM

Baby Lock has created a knife system with a larger cutting bite that cuts thicker fabric with ease and increased visibility.

TUBULAR LOOPERS

There’s no exposed thread, no thread guides and you can thread in any order! Tubular loopers eliminate threading mistakes and protect the thread for more serging freedom.

FABRIC SUPPORT SYSTEM

The Fabric Support System keeps stitches flat and balanced, no matter what speed, fabric or stitch you choose. The built-in stitch fingers actually move with the knife blade, adjusting the seam consecutively with the cutting width.

VERTICAL NEEDLE PENETRATION

While most machines use slanted needles that push and damage fabric, the Acclaim's needles are set vertically and sew directly up and down, protecting your fabric and preventing needle deflection.

DIAL ADJUSTABLE STITCH LENGTH AND AUTOMATIC ROLLED HEM

Stitch length can be easily adjusted on a Baby Lock serger using one dial. This dial includes an Automatic Rolled Hem setting that will retract the built-in stitch width finger for a rolled hem finish.

EXCLUSIVE WAVE STITCH

The patented Wave Stitch opens your world to more decorative stitches for more creativity. Try different thread colors and stitch widths to easily serge a one-of-a-kind creation.

LOOPER DRIVE SYSTEM

This exclusive Looper Drive System prevents loopers from becoming misaligned or out of time, reducing the possibility of major looper damage. This protects your machine from needing repairs, allowing you to serge worry free!

Technical Features

• RevolutionAir Threading System
• Automatic Thread DeliveryTM System
• Pure Lighting with 3 LED lights
• Wide workspace 2" to the right of the needle and 3" tall
• 4/3/2 Thread serging
• Full-Featured Differential Feed:
• 2 to 1 Ratio – gathering
• 3 to 4 Ratio – stretching

Advanced Serging Features

• Exclusive Wave Stitch for additional stitch options
• Rolled hemming with 3 threads
• Flatlock stitching with 2 or 3 threads
• Dial adjustable stitch width: 1.5-7.5mm
• Dial adjustable stitch length: 0.75-4mm
• Dial adjustable built-in rolled hem
• Heavy-duty cutting system
• Precise, patented system makes for easier sewing around curves
• Side thread cutter
• 1,500 Stitches per minute
• Adjustable presser foot pressure dial
• Adjustable presser foot height up to 6.0mm
• Automatic subsidiary looper for two-thread conversion
• Bypass port for specialty threads

Convenience Features

• Thread stand tray with magnet
• Built-in thread cutter
• Electronic foot control
• Presser foot lever on the right
• Easy full-color quick reference threading chart
• Enhanced telescopic antennae with thread guides
• Snap on, multi-purpose presser foot
• Built-in accessory storage
• Built-in ribbon/tape guide
• Needle drop tray with magnet
• Needle clamp safety plate – prevents lost needle screws
• Safety switches for side door cover, front door cover, presser foot, and needle threader
• Power cord manager on machine base

Included Accessories

• Foot control
• Power cord
• Lint brush/needle insert tool
• Package of assorted sized needles
• Allen screwdriver
• Tweezers
• Upper cutting blade for replacement
• Looper threading tool
• Screwdriver
• Machine soft cover
• Four Thread nets
• Four Spool caps
• Four Sponge disks
• Allen wrench
• Four Cone holders
• 4-Thread RevolutionAir needle threading guide

Additional Information

• Household needle system:
• HAx1SP
• ELx705CF
• ELx705
• Weight: 24.6 lbs

Warranty

• 25 years limited
• 10 years parts
• 5 years electrical
• 1 year labor
